WAB-6010, N300 Outdoor PoE Wireless Access Point
Model Number.
WAB-6010
SKU
54621107
The LevelOne WAB-6010 is a managed, outdoor single-band 802.11n wireless access point, capable of 300 Mbps wireless internet speeds. The device runs on 2.4 GHz frequency, and can be used as part of a managed network when controlled by the LevelOne WAC-2000/WAC-2003 Wireless LAN Controller. LevelOne WAB-6010 also offers PoE, removing the need for an external power supply, which makes it easy to install. Advanced weatherproof design, rated to IP65 means the WAP is designed for outdoor deployments, and can withstand rain, humidity, dust, sNAw and extremely hot conditions. A fast, versatile and secure access point for a wide variety of outdoor network requirements.
| Port Configuration | |
|---|---|
| Fast Ethernet RJ45 | 2 |
| 802.3af/at PoE | 1 |
| Logistics Data. | |
| Harmonized System (HS) code. | 851762 |
| Customs product code (TARIC). | 8517620000 |
| Features 1. | |
| Features. | Multi-SSID: 4 SSIDs |
| Miscellaneous. | |
| Frequency band. | 2.4GHz |
| PoE Supported. | Yes |
| Wireless AP type. | Outdoor |
| Max. Wi-Fi Data Rate. | 300Mbps |
| Performance 2. | |
| Receiver sensitivity. |
2.4GHz: 802.11n (MCS0): Range(-90) dBm 802.11n (MCS15): Range (-68) dBm 802.11g 6Mbps: Range (-90) dBm 802.11g 54Mbps: Range (-72) dBm 802.11b 1Mbps: Range (-95) dBm 802.11b 11Mbps: Range (-90) dBm |
| Physical Specifications. | |
| Dimensions (W x D x H). | 87 x 257 x 38 mm |
| Product weight (kg). | 0,4 |
| System Specifications. | |
| Antenna. | 2*5dBi Omni antenna |
| EIRP (dBm). | <20 dBm |
| Encryption. | 64/128-bit WEP WPA-PSK/ WPA2-PSK encryption |
| Frequency band. | 2.4 ~ 2.4835 GHz |
| Mount. | Pole mount |
| Operating modes. | Gateway Mode, Repeater Mode, AP Mode, WISP Mode |
| Power consumption. | <10W |
| Power supply. | Power adapter (ordered separately) |
| Power supply included. | No |
| Standard. |
IEEE 802.11b/g/n IEEE 802.3 10-BASE-T, Ethernet IEEE 802.3u 100-BASE-TX, Fast Ethernet IEEE 802.11e Wi-Fi Multimedia (WMM) IEEE 802.11i Wi-Fi Protected Access (WPA2) IEEE802.3at Power over Ethernet is recommended |
| Wireless channels. | Ch.1 ~ 11 USA, Ch.1 ~ 13 EU |
| Others. | |
| Approval and Compliance. | CE |
| Operating humidity. | 10% RH ~ 90% RH |
| Operating temperature. | -40°C ~ 55°C |
| Storage humidity. | 5% RH ~ 90% RH |
| Storage temperature. | -40°C ~ 70°C |
| Package Contents. |
WAB-6010 Stangenmontage-Schlauchklemme (40 – 64 mm) RJ45-Ethernet-Kabel Ressource CD (Bedienungsanleitung, QIG) Quick Installation Guide |
| General. | |
| Color. | White |
| EAN. | 4015867202333 |
| Model Number. | WAB-6010 |
