IES-0600 6-Port Gigabit Industrial Switch, 4 Gigabit Ports, 1 SFP Slot, 1 SFP/RJ45 Combo Slot, -40°C to 75°C, DIN-Rail Mount
The LevelOne IES-0600 is a rugged 6-port Gigabit Industrial Switch designed for reliable networking in harsh and mission-critical environments. It provides 4 Gigabit Ethernet ports, 1 dedicated Gigabit SFP slot, and 1 shared SFP/RJ45 combo port, offering flexible fiber or copper uplink options for industrial automation, surveillance, and transportation systems.
Built for industrial deployments, the switch supports a wide 9–56V DC input range and includes redundant power inputs via terminal block to ensure continuous operation even if one power source fails. The IP30 metal enclosure, DIN-rail mounting support, and extended operating temperature range from -40°C to 75°C allow the IES-0600 to perform reliably in outdoor cabinets, factory floors, vehicles, and other demanding environments.
With plug-and-play installation, clear LED indicators, and support for a variety of SFP transceivers, the IES-0600 delivers a flexible, durable, and cost-effective industrial Ethernet solution for edge networking applications.
| Logistics Data. | |
|---|---|
| Harmonized System (HS) code. | 851762 |
| Customs product code (TARIC). | 8517620000 |
| Power. | |
| Power Redundancy. | Dual Power Input |
| Miscellaneous. | |
| Grade. | Industrial |
| PoE Supported. | No |
| Manageable. | No |
| Fanless. | Yes |
| Concurrent ports. | Total 6.00 |
| System Specifications. | |
| Data Rate. | 1Gbps |
| Power supply included. | No |
| Power input. |
Power Input: 9-56 VDC Dual power input capable (Redundancy) Protection: Polarity Reversal Overload Current |
| Power consumption. | 5.52W power consumption 48VDC @ 0.12A (unit only) |
| Packet forwarding rate. |
1000Mbps port - 1,488,000pps 100Mbps port - 148,000pps 10Mbps port - 14,880pps |
| Port Configuration. | 5*10/100/1000 Mbps, 2* SFP 1000 Mbps |
| Standard. |
IEEE 802.3 10-BASE-T, Ethernet IEEE 802.3u 100-BASE-TX, Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3z 1000Base-X Gigabit Ethernet IEEE 802.3x Full-duplex Flow Control IEEE802.3x Flow Control and Back Pressure |
| Power Output. | Alarm Relay Output 1A @ 24VDC |
| Mount. | DIN rail mount |
| Flash memory size. | 1024 |
| MAC address table. | 1K |
| Jumbo frame (KB). | 10 |
| Indicators. |
PW1 (Power 1) : Green / PW2 (Power 2) : Green / ERR (Fault) : Amber LNK (RJ45) : Green SPD : Amber (1000) / Green (100) / Off (10) SFP : Green (Link / Active) |
| Dip switch. | DIP 1: OFF: Port 5 SFP (DEFAULT) ON: Port 5 TX , DIP 2: OFF: SFP 1000M (DEFAULT) ON: SFP 100M |
| Backplane (Gbps). | 12 |
| Others. | |
| Approval and Compliance. |
FCC Part 15 Subpart B Class A CE VCCI EN60950-1 EN61000-4-2 (ESD) Level 3 EN61000-4-3 (RS) Level 3 EN61000-4-4 (EFT) Level 3 EN61000-4-5 (Surge) Level 3 EN61000-4-6 (CS) Level 3 EN61000-4-8 (Magnetic Field) Level 3 UL508 (Pending) EN 50121-4 (Pending) IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 UL 508 |
| Operating humidity. | 5% RH ~ 95% RH |
| Operating temperature. | -40°C ~ 75°C |
| Storage humidity. | 5% RH ~ 95% RH |
| Storage temperature. | -40°C ~ 85°C |
| Package Contents. |
IES-0600 Quick Installation Guide |
| General. | |
| Color. | Black |
| EAN. | 4015867188491 |
| Model Number. | IES-0600 |
| Physical Specifications. | |
| Product weight (kg). | 0,72 |
| Dimensions (W x D x H). | 105 x 43 x 142 mm |
