25558307 MPO to LC Trunk Fiber Patch Cord, OM4, Multi-Mode, 12-Fiber, 50/125µm, Aqua, 3m
The MPO to LC trunk fiber patch cord is a multi-mode OM4 fiber cable designed for high-density fiber interconnections in data center and enterprise network environments.
This trunk cable features an MPO connector on one end and LC connectors on the other, enabling efficient backbone cabling and structured fiber deployments where space optimization and simplified installation are required.
Constructed with OM4 50/125µm multi-mode fiber and a 12-fiber configuration, the cable supports high-bandwidth optical transmission. Heat-shrink tubing improves strain relief at the connector transition, while controlled fiber overcut helps ensure consistent optical performance. The aqua-colored jacket provides quick visual identification, and the cable complies with RoHS and REACH requirements.
| Logistics Data. | |
|---|---|
| Harmonized System (HS) code. | 854470 |
| Customs product code (TARIC). | 8544700010 |
| Others. | |
| Approval and Compliance. | RoHS |
| Package Contents. | MPO/LC Trunk Fiber Patch Cord |
| General. | |
| Color. | Violette |
| EAN. | 4015867193242 |
| Model Number. | 25558307 |
| Physical Specifications. | |
| Cable Length. | 3m |
| Dimensions (W x D x H). | 6.5 x 50.5 x 3000 mm |
| Product weight (kg). | 0,18 |
| System Specifications. | |
| Fiber cable type. | OM4 |
| Cable Jacket material. | LSZH |
